Shacman F3000 6X4 $0 ton Dump Truck
Home > Products > 08 Bumper Plate > Shacman F3000 6X4 $0 ton Dump Truck

Shacman F3000 6X4 $0 ton Dump Truck


  • Shacman F3000 6X4 $0 ton Dump Truck
  • Shacman F3000 6X4 $0 ton Dump Truck
  • Shacman F3000 6X4 $0 ton Dump Truck
  • Shacman F3000 6X4 $0 ton Dump Truck
  • Shacman F3000 6X4 $0 ton Dump Truck
  • Shacman F3000 6X4 $0 ton Dump Truck
  • Shacman F3000 6X4 $0 ton Dump Truck

Shacman F3000 6X4 $0 ton Dump Truck

    Packaging: Flat rack, Container, bulker cargo ship or Ro-Ro ship Jinan Howo New Used ZZ3317N4667e1 380Hp 8x4 Dump Truck
    Productivity: 100,000 units per year
    Brand: Sinotruk HOWO
    Transportation: Ocean,Land,Others
    Place of Origin: Jinan, Shandong, China
    Supply Ability: 10000 Unit/Units per Year 8*4 dump truck
    Certificate: ISO9000, CCC, CE, SGS, BV
    HS Code: 8704230090
    Port: Tianjin,Qingdao,Shanghai

Basic Info

Model No.: Shacman F3000

Product Description

China Shacman,

As the biggest heavy truck manufacturer and exporter in China,

Shacman Dump truck is the star production for more than 50 years already. Shacman tipper trucks have been widely exported.

Except for the F3000 dump trucks, we also have F2000 Dumper truck, X3000 rear dump trucks, and H3000 heavy duty lorry trucks for promotion.

Product display

Shacman F3000 6X4 $0 ton Dump Truck

Shacman F3000 Dump Truck

Product parameters

Main specification of Shacman 10 wheeler 35T rear tipper truck

Model SX3255DV384C
Drive type 6×4
Type Dump Truck
Weight
Complete kerb mass(kg) 14,500
Loading capactiy(kg) 26,500
GVW(kg) 41,000
Performance
Max.speed(km/h) 77
Min.ground clearance(mm) 314
Approach/Departure angle(°) 28/30
Max.gradeability(%) 33
Dimensions
Max.length(mm) 8,330
Max.width(mm) 2,490
Max.height(mm) 3,450
Wheel base(mm) 3,775+1,400
Engine
Make WEICHAI
Type WP10
Rated Output(kw/HP) 375
Maximum torque(N.m)/rpm 2,010/1,200
Rated speed(r/min) 1,900
Displacement(L) 10.8
Emmission Standard Euro III
Transmission
Make FAST GEAR
Model 12JSD200T
Control type Manual, with sychronizer
Gear Shift 12 forward and 2 reverse
Gear ratio 15.53 12.08 9.39 7.33 5.73 4.46 3.48 2.71 2.10 1.64 1.28 1.00 R: 14.86 3.33
PTO QH50
Clutch
Make EATON
Type Spring plate,diaphragm spring
Diameter(mm) φ430
Braking system
Type Drum brake
Service brake Dual-circuit compressed air brake
Park brake Power spring brake acting on rear wheels
Auxiliary brake JACOB
WABCO ABS with 6 channels
Frame
Type Parallel straight ladder structure of type "C" section
Dimension 850×300(8+7), with double layers
Suspension
Front Semi-elliptic springs
Rear Trapezoidal leaf springs with stabilizer bar
Steering system
Type ZF8098
Axles
Make HANDE--MAN
Front axle 9.5T
Rear axles 16T×2 Double reduction driving axles with differential locks and hub reductors
Ratio 5.262
Tires
Type 12.00R20 NEW
Numbers 10
Fuel tank
Tank capacity(L) 400
Material Aluminium
Electrics system
Type 24V
Battery 180Ah
Others Reversing buzzer, Rear frame lamp, Rear lamp protectors, ETA Circuit Breaker, 2 kg fire extinguisher, Fleetguard air filters
Cabin
Type SHACMAN F3000, flat roof
Standard equipments 1. Hydraulic suspension for cabin
2. Automatic A/C
3. Air-suspension driver seat
4. One bunker
5. Hydraulic reversal cab
6. Metal bumper
7. Electric windows lifting system(with MABUCHI motor)
8. Cruise control system switch

9. Radio with USB
Dumper body
Lifting system Ф180
Front-lifting system
Max. lifting weight(kg) 40,000
Body type bottom 8mm side 6mm
Body dimensions(mm) 5,600×2,300×1,500 NEW BUCKET

Product details


IMG_20201008_102552

truck details



Product application

2014-04-21 13.14.54




Packaging and shipment


We have professional packing team to design the suitable shipment method for you based on the quantity.

As the VVVVVIP of shipping forwarder, we can get the cheapest shipping cost than anyone to help you save shipping cost.

1> By flat rack ship

Shacman F3000 Dump Truck

2> By Ro-Ro ship

shacman tipper truck

3> By bulk cargo ship

Shacman Dump Truck




Factory display
Shanxi Heavy duty Truck Co.,Ltd. established in 2005 is one of the qualified manufacturers of various trailers. Integrated production, scientific research & development and professional sales teams, all those advantages can provide the full service of trailers, semi-trailers, tractor head, dump truck, engineering machinery and trailer parts, our company is a leading provider in this industry, with annual export value reaching above 50million dollars and revenue almost 600 million yuan RMB.With high standard machinery and automatic equipment, powerful R&D team and elite sales team, We have built a long business relationship with many world famous enterprises such as SINOTRUK\SHACMAN\FAW\DFAC\XUGONG Group\LIUGONG Group\SEM Group etc. Besides mature after-sale systems, we can meet different needs of customers both home.


photobank (8)

certificate

Sinotruk howo tipper trucks are been exported to most of the world already with high reputation.

It's easy to get the maintenance and truck parts at local market

Also we could oofer you any service you need

certificate

Customer cooperation


Our lovely customers visited us in spot for long-term cooperation relationship.

Sincerely welcome to your visit soon


Looking forward to our first cooperation in the soon future

Successful cases

With the biggest production factory, the most strong technical team

Our dump trcks are the best products

Here below are what we have exported.

photobank (10)

Customer feedback

With more than 10 years working experience, I am not only a professional saleswoman,

also a professional technical person.

I have exported moe than 1000 units tipper trucks to the whole world,

Look at my customers' feedback

You will never regret to cooperate with me

photobank (9)

contact us

Aimee Liang
Sales Manager
Mobile/ Whatsapp/: +86-178 5310 6971
Linked in: Aimee Liang


82f120a74e27007cdab8172be8

FAQ
1. who are we?
We are based in Shandong, China, start from 2017,sell to Africa(40.00%),Southeast Asia(20.00%),Southeast Asia(20.00%),Oceania(10.00%),Central America(10.00%),Oceania(10.00%),South America(8.00%),South Asia(6.00%),Mid East(4.00%),Mid East(4.00%),Eastern Europe(2.00%),Eastern Europe(2.00%). There are total about 11-50 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Truck Trailer,Truck,Trailer Parts,Truck Parts

4. why should you buy from us not from other suppliers?
Established in 2005,our plant is one of the qualified manufacturers of various trailers. 1.Factory direct price 2.Customized products,Diversified products 3.Leading production technology on truck trailer 4.Professional Sales Team

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Spanish,Portuguese,Arabic,French




Shandong Chengda Auto Sales Co., Ltd.

 Shandong Yuncheng Chengda Trailer Manufacturing Co., Ltd as a manufacture factory and Shandong Chengda Auto Sales Co.,Ltd., Sinotruck Howo Sales Co., Ltd. Cd Special Truck Ltd. as the sales company. Our Factory established in 2 0 0 5, it`s a professional supplier engaged in the scientific research, production, sale and service of various of semi trailers, trucks and trailer and truck spare parts. we can provide full service of truck trailers, trucks and spare parts. Chengda Team including sales and documentary and after sales service for orders successful proceeding. we are dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to meet your requirements and ensure customer satisfaction. We had exported to 55 countries and regions such as Africa, South America, Middle East, East Asia,South Asia, Southeast Asia, Oceania. Moreover, we have agents in the Philippines, Malaysia, Nigeria,Ghana, Cote d`ivoire, Malawi,Zimbabwe, Zambia,Tanzania, Kenya,Uganda,Mozambique,Haiti,. Our company`s future vision is become a globally-famous and long-standing corporation and our mission is sharing interests and happiness with all partners. Choosing Chengda company is to choose a better solution of transportation. Come here and choose the proper products, customers can enjoy great purchase experience from our professional team. With mature after-sales systems, our commitment to you do not end after you receive the cargo from our company as it is just beginning, Chengda company welcome customers all over the world to visit our factory.
